Ionbond™ 25

PVD Coating for use in metal forming applications

Ionbond™ 25 is an AlCrN coating that possesses high hardness and excellent wear resistance. This combination of properties makes Ionbond™ 25 a good coating candidate for piercing, blanking, and trimming applications involving carbon steels, austenitic stainless steels, galvanized, prepainted or coated steels and advanced high strength steels (AHSS).

Ionbond™ 25’s excellent wear resistance also enables it to enhance the performance of tools used in powdered metal compaction applications. Ionbond™ 25 has excellent thermal stability, which, when combined with nitriding, enables it to be used successfully in high temperature forming applications. One particular high temperature application well suited for Ionbond™ 25 is the hot stamping of AHSS materials where both thermal stability and high wear resistance are indispensable.

Ionbond™ 25 is generally deposited between 450-550 °C. These processing temperatures require tool materials to be tempered at higher temperatures in order to avoid softening or dimensional changes.

Technical data

Material AICrN

Technology PVD Arc

Thickness range [µm] 2 - 4 µm

Microhardness, HV 3000

Friction vs. Steel (dry) 0.55

Service Temperature 1050°C

Process Temperature 450 - 550°C

Color Grey

Download factsheet
